Working principle and introduction of flipping air dryer:
The machine is continuously flipped to effectively remove water droplets on the surface of the material, making the surface shiny, bright and free of stains. It shortens the time for labeling and packing, and is suitable for assembly line operations to improve the automation of production. The air dryer is divided into normal temperature and high temperature to effectively protect the color and quality of the material itself.
This machine is especially suitable for the drying of small package vacuum bagged products such as high and low temperature meat products and vegetable products after sterilization.
How to turn the air dryer:
The inverted wind trunk line mainly consists of a mesh belt conveying system, a fan system, and a frame body. The whole machine is made of SUS304 stainless steel, which is hygienic and environmentally friendly, and does not damage the product.
Mesh belt conveyor system: The belt conveyor system uses the variable frequency motor as the power source and the running speed is adjustable. The drive shaft transmits power, the chain drives, runs smoothly, and has a long service life. The whole transmission system is supported by the mesh belt bracket rail, which is easy to operate and maintain. The mesh belt can be turned over at a distance to ensure that the double-sided moisture and other substances are removed, and the moisture on both sides of the product can be removed. The bottom of the conveyor belt has square steel support to ensure that the belt will not deform for a long time.
The mesh belt tensioning system is driven by the screw thread, and the tension is large, simple and firm. The mesh belt can be moved more easily and freely, and can be accurately positioned. Easy to operate, durable and durable.
Fan system: The fan system is composed of multiple snail fans. The equipment is equipped with two or three snail fans at intervals, ensuring uniform airflow distribution.
Frame: The frame is made of 304 stainless steel plate and stainless steel square tube.
Turn over the working principle of the air dryer , flip the air dryer to remove the water directly after packing, and the air dryer realizes continuous operation (used with the continuous working sterilization machine), and only needs to put the sterilized product into the conveyor belt, which is produced by the air dryer. The airflow is sprayed out through the nozzle, and the blown air temperature is normal temperature, and the air dryer effectively protects the color and quality of the material itself. In order to achieve the effects of packaging water removal, degreasing, scale, etc., it can be packed into the warehouse.
Flip the air dryer line picture:
